Vic-3D v11.0 | Digital Image Correlation (DIC) Software for 3D Deformation & Strain Measurement
Vic-3D v11.0 is a leading-edge software platform for performing non-contact, full-field 3D deformation and strain measurement using Digital Image Correlation (DIC). It analyzes synchronized images from stereoscopic camera systems to provide precise, quantitative data on material behavior, structural response, and component performance under load.
Core Functionality Overview:
-
Full-Field 3D Displacement & Strain Analysis: Calculates high-resolution 3D shape, displacement, and strain fields (Lagrangian, Eulerian) across the surface of a test specimen using advanced correlation algorithms.
-
Dynamic & High-Speed Testing Capabilities: Supports analysis of both static and dynamic events, including high-speed camera data for capturing impact, vibration, and fatigue testing.
-
Integrated Data Management & Visualization: Provides tools for data filtering, virtual extensometers, contour plots, and export to standard formats (CSV, HDF5), with powerful 3D visualization for result interpretation.
