EUKLID CAD/CAM is a highly efficient 3D CAD/CAM system for tool, mold and model making which, in the long run, guarantees you important cost, time and quality advantages.
EUKLID CAD/CAM offers unrivaled user support, with a wide variety of functions for creating easy to manufacture surface models. Additional industry-specific functions (forge, cast, impeller and tire) allow fast and efficient knowledge transfer.
All CAD-functions offered by EUKLID CAD/CAM are practical, highly efficient and easy to learn and understand. Two major benefits of using EUKLID are the high degree of flexibility offered and the ease with which later modifications can be made. Of course, functions for volume calculation, shrinking of models and pattern partition are included in basic EUKLID. Processing most demanding surface models with highly complex blendings and draft surfaces is a specialty of EUKLID CAD/CAM.
CAM Machining
The ease of 5-axis gear milling
A gear wheel, with its 15 to 100 tooth spaces of identical geometry and properties, corresponds to a small batch in machining. Subject to the given tolerances, EUKLID GearCAM optimizes the milling paths to get a minimum number of paths while strictly adhering to the tolerances. The cutting and performance data may be loaded from a configurable tool database.
