CGen PCB – Impedance coupon generator/ CGen Si – Insertion loss coupon generator
CGen Coupon Generator reduces the time-consuming process of creating impedance coupons manually to just a few minutes, adding powerful new features that give coupon generation new levels of control and flexibility.
CGen PCB Coupon Generator is an automatic impedance coupon generator that allows you to create a controlled impedance test coupon from scratch or import finished stacks from Speedstack PCB and Speedstack Si or structures from the Polar Si8000 and Si9000 field solvers.
CGen Si incorporates all the features of CGen PCB and adds insertion loss coupon capability. Please note designs for insertion loss coupons need to be fine tuned to OEM requirements and final adjustment of launch and via structures may still be required. If in any doubt – please check with your design authority
CGen generates the appropriate impedance/insertion loss test coupon containing all the required PCB controlled impedance transmission line structures, reducing what is normally a time consuming process to minutes.
Importing structures from the Si8000m or Si9000e
CGen is fully compatible with the industry standard Polar Si8000m controlled impedance field solver and the Si9000e frequency dependent, lossy line GHz field solver.
